Pulley Block / Snatch Block
Yulong pulley blocks (also called snatch blocks or sheave blocks) are essential components in wire rope rigging systems. They change the direction of a wire rope, provide mechanical advantage in lifting systems, and enable complex reeving configurations. Available in single-sheave, double-sheave, and multiple-sheave configurations with either cast iron or steel pulleys to suit different load and environmental requirements.
- Ductile iron or steel sheaves with precision-machined rope grooves
- Sealed ball bearings or bronze bushings for smooth rotation
- Forged steel shackles and swivel hooks with safety latches
- Snatch block design with hinged side plate for easy rope installation
- Galvanized or painted finish for corrosion resistance
- High safety factor (4:1 for lifting, 5:1 for personnel applications)
Technical Specifications
| Model | Capacity (kg) | Sheave Dia. (mm) | Wire Rope Dia. (mm) | No. of Sheaves | Bearing Type | Net Weight (kg) |
|---|---|---|---|---|---|---|
| YL-PB01 | 1000 | 100 | 6–8 | 1 | Ball bearing | 3.5 |
| YL-PB02 | 2000 | 150 | 8–10 | 1 | Ball bearing | 5.8 |
| YL-PB05 | 5000 | 200 | 10–13 | 1 | Ball bearing | 11.2 |
| YL-PB10 | 10000 | 300 | 13–16 | 1 | Bronze bushing | 22.0 |
| YL-PB20 | 20000 | 400 | 16–20 | 2 | Bronze bushing | 45.0 |
| YL-PB50 | 50000 | 500 | 20–26 | 3 | Bronze bushing | 95.0 |
Applications
- Crane reeving systems
- Construction hoisting
- Marine & offshore rigging
- Mining & cableway systems
- Stage & theatre rigging
- Tensioning cable systems
- Search & rescue operations
All Yulong pulley blocks are load-tested and certified. Snatch block designs are available for quick side-loading of the rope without threading. Custom sheave diameters, multi-block assemblies, and stainless steel marine-grade options available upon request.
