Manual Chain Block 1-20 Ton — HSZ Series Hand Hoist G80 Chain
HSZ (national standard light-duty) and HS (standard) series manual chain blocks, built with G80 manganese steel load chain. Manual brake, designed for no-power lifting on construction sites and industrial workshops.
Single fall — for capacities up to 2T, one chain fall, lighter and more portable.
Multiple falls — 2/4/8 chain falls for 3T–20T, distributing load for safe heavy lifting.
Technical Specifications — HSZ Series (Standard Lift 3m)
| Model | Capacity (t) | Std Lift (m) | Hand Pull Force (N) | Chain Falls | Chain Dia. (mm) | Net Weight 3m (kg) | Add per +1m (kg) | Test Load (t) |
|---|---|---|---|---|---|---|---|---|
| HSZ1 | 1 | 2.5/3 | 300 | 1 | 6 | 10 | 1.0 | 1.5 |
| HSZ1.5 | 1.5 | 3 | 340 | 1 | 8 | 16 | 1.2 | 2.25 |
| HSZ2 | 2 | 3 | 360 | 1 | 8 | 14 | 1.3 | 3.0 |
| HSZ3 | 3 | 3 | 380 | 2 | 8 | 24 | 1.8 | 4.5 |
| HSZ5 | 5 | 3 | 420 | 2 | 10 | 36 | 2.5 | 7.5 |
| HSZ10 | 10 | 3 | 450 | 4 | 10 | 68 | 4.0 | 15 |
| HSZ20 | 20 | 3 | 480 | 8 | 10 | 155 | 7.0 | 30 |
Common Specifications
- Load chain: G80 high-strength manganese steel; hand chain: standard carbon steel
- Brake system: Friction disc one-way self-locking brake with dual pawl anti-drop — locks instantly when pulling stops, load will not slip
- Hooks: Forged alloy steel upper and lower hooks with safety latches, 360° swivel; hook breaking load ≥ 4× rated capacity
- Safety standard: Overall safety factor 4×; factory proof load test at 1.5× rated capacity; working temperature -20°C to +60°C
- Custom options: Extended lift heights 6m / 9m / 12m / 18m; explosion-proof (non-sparking) and stainless steel anti-corrosion models available
Capacity Selection Guide
- 1T–2T: General workshop lifting, pipe installation, mold handling — most common models
- 3T–5T: Heavy equipment, steel structure, large construction components
- 10T–20T: Large machinery assembly, bridge construction, heavy components — multi-fall chain, heavier self-weight
All Yulong HSZ series manual chain blocks are tested at 1.5× rated capacity before leaving the factory. Each unit comes with a safety certificate and operation manual. Custom lift heights and corrosion-resistant options available for specialized applications.
