Complete Hydraulic Jack Series: Single-Stage & Dual-Stage (5-50 Tons)
Series Overview
Our comprehensive range of hydraulic jacks from 5 to 50 tons is engineered to meet every professional lifting need. Choose between our reliable Single-Stage jacks for standard-height tasks or our high-performance Dual-Stage jacks for applications requiring exceptional lift height.
Product Line Comparison
| Feature | Single-Stage Jack Series | Dual-Stage (Telescopic) Jack Series |
|---|---|---|
| Piston Design | Single, solid piston rod. | Two-stage telescopic piston. |
| Core Advantage | Robust construction, direct force transfer, often more compact. | Significantly greater lifting range from a low starting height. |
| Lifting Height | Standard, suitable for most common vehicles. | Extended maximum height, ideal for high-clearance vehicles. |
| Best For | Workshops, frequent tire changes, general maintenance of cars, vans, SUVs. | 4x4s, lifted trucks, agricultural machinery, industrial applications needing extra workspace underneath. |
| Durability | Excellent; simpler design with fewer moving parts. | Excellent; built for heavy-duty cycles with reinforced stages. |
| Price Point | Competitive, cost-effective. | Premium for enhanced capability. |
Complete Dimensional Specifications: 5-50 Tons
| Capacity | Single-Stage Jack | Dual-Stage (Telescopic) Jack |
|---|---|---|
| 5 Ton | Min. Height: ~180-190 mm Max. Height: ~320-360 mm |
|
| 8 Ton | Min. Height: ~195-200 mm Max. Height: ~330-370 mm |
Min. Height: ~190-200 mm Max. Height: ~450-500 mm |
| 10 Ton | Min. Height: ~190-205 mm Max. Height: ~340-380 mm |
Min. Height: ~195-210 mm Max. Height: ~440-480 mm |
| 12 Ton | Min. Height: ~195-210 mm Max. Height: ~350-390 mm |
Min. Height: ~210-225 mm Max. Height: ~460-565 mm |
| 16 Ton | Min. Height: ~210-225 mm Max. Height: ~400-420 mm |
Min. Height: ~205-220 mm Max. Height: ~470-510 mm |
| 20 Ton | Min. Height: ~220-235 mm Max. Height: ~390-440 mm |
Min. Height: ~285-290mm Max. Height: ~570-585 mm |
| 30 Ton | Min. Height: ~220-240 mm Max. Height: ~400-450 mm |
|
| 45 Ton | Min. Height: ~240-260 mm Max. Height: ~430-500 mm |
